Product Code: MCRC031ATD

Compact design, ideal for installations with limited space Convenient and secure wiring with screw terminals for ease of installation Suitable for residential, commercial and industrial settings Options for wall or rail mounting to accommodate different installations needs

Specifications

Mounting Type	DIN Rail
Operational Temperature Range (°C)	-40 to +55
Brand	ABB
Product Type	Mini Contactor Relay
Series	M
Actuating Voltage Type	DC
Auxiliary Contacts	3NO/1NC
Connection Type	Screw Connection for Auxiliary Circuit
Mode of Operation	DC
No. of Normally-closed Auxiliary Contacts	1
No. of Normally-open Auxiliary Contacts	3
No. of Poles	4
Operating Voltage AC (V)	690
Operating Voltage DC (V)	440
Operating Voltage Type	DC
Power Loss (W)	0.4/pole
Rated Control Circuit Voltage DC (V)	24
Rated Control Supply Voltage DC (V)	24
Rated Frequency (Hz)	50/60
Rated Impulse Withstand Voltage (kV)	6
Rated Insulation Voltage (V)	750
Rated Operational Current (A)	6
Rated Operational Current AC-15 240V (A)	6
Rated Operational Current AC-15 400V (A)	4
Rated Operational Voltage AC (V)	690
Rated Supply Voltage AC (V)	24
Short-Circuit Protective Device	10A, fuse type gG
Terminal Type	Screw
Dimensions (mm)	45W x 48H x 68D
Degree of Protection	IP20

Description

The MCRC031ATD mini contactor relay is a dimension optimized 4 pole contactor relay with screw terminals. This device is a great solution when high performances are needed but the space is limited. Mini contactors are used in residential buldings, commercial buildings and industrial applications for switching of control signals up to 6 A / 240 V (AC-15). The product is suitable for wall or rail mounting.
