Specifications

Enclosure Material	Polyarylate
Cable Type	3 core cabtyre
Storage Temperature (°C)	-30 to +70
Relative Humidity	35 to 85%
Gross Weight (g)	50
Net Weight (g)	20
Ambient Temperature (°C)	-25 to +55
Brand	PANASONIC
Product Type	Photoelectric Sensor
Current Consumption (mA)	<13
Illuminance (lx)	3000
Insulation Resistance (MO)	20
Operation Indicator	Orange LED (indicaties when output = ON)
Output Operation	Light-ON
Outputs	PNP
Rated Supply Voltage DC (V)	12 to 24
Resistance to Shock (m/s²)	500
Response Time (ms)	<0.5
Sensing Range (mm)	2 to 25
Sensor Type	Standard Convergent Reflective Diffused Beam
Cable Cross Section (mm²)	0.1
Cable Length (m)	2
Dimensions (mm)	10W x 14.5H x 3.5D
Utilization Category	DC-12 or DC-13
Withstand Voltage AC (V)	1000 for 1 minute
Degree of Protection	IP67
Pollution Degree	3 (Industrial Environment)
