Specifications

Actuator Type	Roller lever H65 and bearing block B
Enclosure Material	Glass-fibre, reinforced thermoplastic
Storage Temperature (°C)	-25 to 70
Maximum Ambient Temperature (°C)	70
Minimum Ambient Temperature (°C)	-25
Gross Weight (g)	50
Net Weight (g)	50
Wire Cross-Section	0.14 mm
Enclosure Coating Material	Painted
Brand	SCHMERSAL
Product Type	Micro Switch
Working Principle	Electromechanical
Housing Construction Form	Norm construction design
EAN	4030660000000
eCl@ss Number, Version 9.0	27-27-26-03
Coding Level According to EN ISO 14119	Low
ETIM 7.0	EC001029
ETIM 6.0	EC002593
eCl@ss Number, Version 11.0	27-37-12-12
Cable Note	All indications including the conductor ferrules.
Contact Material	Silver
Maximum Actuating Speed (m/s)	0.5
Maximum Cable Cross Section (mm²)	2.5
Maximum Fuse Rating	6 A (slow blow)
Minimum Actuating Speed (mm/min)	1
Minimum Cable Cross Section (mm²)	0.75
Minimum Mechanical Life	10000000 Operations
Minimum Positive Break Force (N)	20
No. of Auxiliary Contacts	2
No. of Safety Contacts	1
Overvoltage Category	3
Rated Impulse Withstand Voltage (kV)	6
Rated Insulation Voltage (V)	500
Rated Short-circuit Current (A)	1000
Resistance to Shock (g/ms)	30 / 11
Switching Element	1 NO contact, 1 NC contacts
Switching Principle	Slow action
Terminal Type	Screw terminals M20 x 1.5
Utilisation Category	DC-13 \| AC-15
Utilisation Category DC-13	0.25 A
Sensor Length (mm)	30
Sensor Height (mm)	90
Degree of Protection	IP67 / IP65
Standards	EN IEC 60947-5-3 / BG-GS-ET-14
