SCHMERSAL SD-I-U-EIP CONTROL PANEL 101210747

Product Code: 101210747

  • Solenoid interlock for machine safety Variable latching force ranging from 30 N to 100 N Compact dimensions: Width 26 mm x Height 38 mm x Depth 11.5 mm Part of the MZM100 series
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Enclosure Material Plastic, glass-fibre reinforced thermoplastic, zinc die-cast, chromated
Maximum Ambient Temperature (°C) 50
Maximum Temperature (°C) 55
Minimum Ambient Temperature (°C) -10
Minimum Temperature (°C) 0
Gross Weight (g) 280
Net Weight (g) 1260
Brand SCHMERSAL
Product Type Accessory
Series SD-I
EAN 4030660000000
eCl@ss Number, Version 9.0 27-37-12-43
ETIM 7.0 EC002593
ETIM 6.0 EC000041
eCl@ss Number, Version 11.0 27-37-12-43
Contact Material Silver
Maximum Fuse Rating 6 A gG D-fuse
Minimum Mechanical Life 20000000 Operations
Rated Maximum Operational Voltage DC (V) 24
Terminal Type Screw terminals M20 x 1.5
Utilisation Category AC-15 230 VAC
Utilisation Category DC-13 24 VDC
Sensor Length (mm) 38
Sensor Height (mm) 356
Degree of Protection IP20
Standards EN ISO 13849-1

Description

Enhance your machine safety with the Schmersal SD-I series control panels, designed for seamless integration into your industrial network via EtherNet IP. These robust units feature cage clamp terminal connectors and operate efficiently on a 24 VDC power supply with a flexible voltage range. With an operating current of 500 mA, these control panels are a reliable choice for maintaining safety standards in demanding environments.
