Brand	ABB
EAN	8015644024406
Breaking Capacity 415V AC - Icu (kA)	70
Current Rating (A)	160
Design of Control Element	Toggle
L (0.4 to 1 x In) - I1 (A)	64 - 160
Main Circuit Electrical Connection	Bolt Connection
Main Current Circuit Connection Position	Front Side
No. of Poles	4
Overload Release Current Setting (A)	64
Power Loss (W)	8.9
Rated Current (A)	160
Rated Instantaneous Short-Circuit Current - Ii (A)	160
Rated Uninterrupted Current - Iu (A)	160
Rated Voltage (V)	690
S/I (1 to 10 x In) - I2/I3 (A)	160 - 1600
Size of Frame	XT4
Trip Unit	Ekip DIP LS/I
Degree of Protection	IP20
MCCB Type	XT4 Frame
Poles	4P
Breaking Capacity (kA)	70
Tripping Unit	Ekip DIP LS/I
Trip Unit - Electronic	Ekip DIP LS/I

Moulded Case Circuit Breakers

ABB XT4H 160 EKIP LS/I IN=160A 4P F F 1SDA068534R1
