ABB ESB16-02N-06 INSTALLATION CONTACTOR (NC) 16 A - 0 NO - 2 NC - 230 V - CONTROL CIRCUIT DC ESB1602N06

Product Code: ESB1602N06

In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Width in Number of Modular Spacings 1
Brand ABB
Product Type DIN Contactor
Excitation Voltage Type AC/DC
Hum-free Yes
No. of Normally-closed Contacts 2
Operating Voltage Type AC/DC
Rated Control Circuit Voltage (V) 230
Rated Operational Current (A) 16
Rated Operational Voltage AC (V) 250
Rated Operational Voltage DC (V) 220
Utilization Category AC-1 According to EN IEC 60947-4-1
Built-in Depth (mm) 58
Degree of Protection IP20

Description

The ESB16..N installation contactors are used to control single loads up to 16 A and can be operated by AC or DC. These contactors are made for use in household applications as well as in industrial environments. The following benefits are provided: Hum-free operation, low power consumption and integrated overvoltage protection. Various contact combinations and accessories are available.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
