Specifications

Ambient Temperature Range (°C)	-5 to 55
Brand	ABB
Product Type	RCBO
No. of Poles	3+N
No. of Protected Poles	3
Power Loss (W)	6.5
Rated Current (A)	20
Rated Frequency (Hz)	50 - 60
Rated Impulse Withstand Voltage (kV)	4
Rated Insulation Voltage (V)	500
Rated Operational Voltage (V)	415
Rated Residual Current (mA)	100
Rated Short-Circuit Capacity - Icn (kA)	10
Dimensions (mm)	53.4W x 117.5H x 71.6L
Trip Curve	D
Type of Residual Current	Type A
Weight (kg)	0.549
Standards	IEC 61009-1 IEC 61009-2-2 AS/NZS 61009-1
