IDEC SAFETY SWITCH PLASTIC HEAD 2NC HS5D-02ZRN

Product Code: HS5D-02ZRN

The IDEC HS5D-02ZRN Safety Switch features a durable plastic head with 2NC contacts for secure circuit control. It includes an M20 gland port for cable connections and offers easy wiring options. The switch is designed to detect detachment of the head, adding an extra layer of safety. Its compact size allows for up to three contacts, and it's also available with a metal head option. With a high B10d value of 2.0E+08, it ensures reliable performance in safety-critical applications.

Technical Specifications

Operating Humidity 45 to 85%
Resistance to Shock (m/s²) 1000
Brand IDEC
Operational Temperature Range (°C) -30 to 70
Minimum Electrical Life 100000
Minimum Mechanical Life 1000000
Rated Insulation Voltage (V) 300
Rated Thermal Current - Ith (A) 10
Resistance to Vibrations 10 to 55Hz
Weight (g) 80g - Plastic Head, 110g - Metal Head
Degree of Protection IP67
