Specifications

Actuator Type	Plunger
Enclosure Material	Plastic, glass-fibre-reinforced
Storage Temperature (°C)	-25 to 85
Maximum Ambient Temperature (°C)	80
Minimum Ambient Temperature (°C)	-15
Gross Weight (g)	40
Net Weight (g)	35
Wire Cross-Section	0.25 mm
Brand	SCHMERSAL
Product Type	Safety Switch
Working Principle	Electromechanical
Housing Construction Form	Norm construction design
EAN	4030660000000
eCl@ss Number, Version 9.0	27-27-27-04
ETIM 7.0	EC002544
ETIM 6.0	EC002549
eCl@ss Number, Version 11.0	27-27-27-04
Cable Note	All indications including the conductor ferrules.
Contact Material	Silver
Maximum Actuating Speed (m/s)	1
Maximum Cable Cross Section (mm²)	1.5
Maximum Fuse Rating	6 A gG D-fuse
Minimum Cable Cross Section (mm²)	0.75
Minimum Mechanical Life	10000000 Operations
Minimum Positive Break Force (N)	40
No. of Auxiliary Contacts	1
No. of Safety Contacts	2
Overvoltage Category	3
Rated Impulse Withstand Voltage (kV)	6
Rated Insulation Voltage (V)	500
Rated Short-circuit Current (A)	1000
Switching Element	1 NO contact, 2 NC contacts
Switching Principle	Slow action
Terminal Type	Connector
Thermal Test Current (A)	2.5
Utilisation Category	DC-13 \| AC-15
Utilisation Category DC-13	0.05 A
Sensor Length (mm)	32.5
Sensor Height (mm)	150.5
Degree of Protection	IP65
Standards	EN IEC 61496-1 / EN IEC 61496-2
