SCHMERSAL AZ415-11/11ZPK-M20 SAFETY SWITCH WITH SEPARATE ACTUATOR 101154000

Product Code: 101154000

  • Safety-related tactile sensor Part of the SE-400C series by Schmersal Stop-Category 0 for emergency stop functions Features electronic fuse and wire breakage detection Short-circuit recognition capability Includes start input and feedback circuit Automatic reset function with reset edge detection Resets after disconnection of supply voltage Earth connection detection feature included
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Actuator Type Roller lever
Enclosure Material Aluminium
Storage Temperature (°C) -40 to 85
Maximum Ambient Temperature (°C) 80
Maximum Temperature (°C) 80
Minimum Ambient Temperature (°C) -30
Minimum Temperature (°C) -25
Gross Weight (g) 65
Net Weight (g) 35
Wire Cross-Section 0.25 mm
Brand SCHMERSAL
Product Type Safety Switch
Series AZ415
Working Principle Electromechanical
Housing Construction Form Norm construction design
EAN 4030660000000
eCl@ss Number, Version 9.0 27-06-03-11
Coding Level According to EN ISO 14119 Low
ETIM 7.0 EC001029
ETIM 6.0 EC002887
eCl@ss Number, Version 11.0 27-27-27-92
Cable Note All indications including the conductor ferrules.
Contact Material Silver
Maximum Actuating Speed (m/s) 0.3
Maximum Cable Cross Section (mm²) 1 x 1.5 , flexible
Maximum Fuse Rating 6 A gG D-fuse
Minimum Cable Cross Section (mm²) 0.34
Minimum Mechanical Life 1000000 Operations
Minimum Positive Break Force (N) 40
No. of Auxiliary Contacts 1
No. of Safety Contacts 1
Overvoltage Category 3
Rated Impulse Withstand Voltage (kV) 4
Rated Insulation Voltage (V) 250
Rated Short-circuit Current (A) 1000
Switching Element Normally open contact (NO)
Switching Principle Slow action
Terminal Type Screw terminals M20 x 1.5
Utilisation Category DC-13 | AC-15
Utilisation Category DC-13 0.05 A
Sensor Length (mm) 33
Sensor Height (mm) 171.5
Degree of Protection IP67
Standards EN IEC 61076-2-111

Description

Enhance your machine safety with the Schmersal AZ415 safety switch, designed for robust performance with a metal enclosure and spring-loaded actuators that ensure a higher latching force. This switch is equipped with three auxiliary contacts and one safety contact, suitable for single guard door applications. The screw connection terminal ensures secure wiring, while the switching element includes both NO and NC contacts. With a thermal test current of 6 A, it operates efficiently at 230 VAC under AC-15 utilization category with a 4 A rating, and at 24 VDC under DC-13 utilization category also with a 4 A rating. Trust in Schmersal's commitment to reliable machine safety solutions.
