Specifications

Enclosure Material	Plastic, glass-fibre reinforced thermoplastic, self-extinguishing
Maximum Ambient Temperature (°C)	80
Minimum Ambient Temperature (°C)	-25
Gross Weight (g)	125
Net Weight (g)	320
Brand	SCHMERSAL
Product Type	Safety Sensor
EAN	4030660000000
eCl@ss Number, Version 9.0	27-27-26-02
ETIM 7.0	EC001449
ETIM 6.0	EC002592
eCl@ss Number, Version 11.0	27-27-26-02
Minimum Mechanical Life	10000000 Operations
Terminal Type	Screw terminals M20 x 1.5
Utilisation Category AC-15	240 VAC
Utilisation Category DC-13	24 VDC
Sensor Length (mm)	30
Sensor Height (mm)	35
Degree of Protection	IP66 / IP67
Standards	EN IEC 60947-5-1 / EN ISO 13849-1 / BG-GS-ET-15
