NOVARIS NOVARIS SURGE PROTECTOR, 230VAC, 63A SSP1-63-100-275-A

Product Code: SSP1-63-100-275-A

  • - Compact design - All Mode Protection - LED status & Active alarm - Installation independent performance - Safe metal enclosure
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Lightning Impulse Current (10/350 µs) - Iimp (kA) 12.5 (L-N), 15 (N-PE)
Mounting Type DIN rail
Operational Temperature Range (°C) -40 to 70
Brand NOVARIS
Product Type Surge Protection Device
Series SSP1
Alarm Contact Yes
Connection Type Series
Maximum Continuous Operating Voltage MCOV AC (V) 275 (L-N), 255 (N-PE)
Maximum Discharge Current (8/20µs) - Imax (kA) 100 (L-N) 60 (N-PE)
Maximum Load Current - I? (A) 63
No. of Phases 1
No. of Poles 1P+N+PE
Nominal Discharge Current (8/20µs) - In (kA) 40 (L-N), 50 (N-PE)
Nominal Voltage AC (V) 230
Dimensions (mm) 72W x 69H x 95L
Weight (g) 460
Voltage Protection Level - Up (kV) <1.7 (L-N)
Degree of Protection IP20
Standards and Approvals IEC 61643-11, AS/NZS 1768, UL 1449, IEEE 62.41.2

Description

: The Novaris SSP1 Series Surge Protectors are designed to provide comprehensive surge protection for AC power circuits. With a robust design and all-metal enclosure, these devices ensure safety and reliability in various industrial environments. The compact form factor makes them suitable for space-restricted applications, while the multiple standards compliance ensures broad compatibility.
