ABB SRG PROT TYPE T2 80KA 3PH+N0 2CTB815708R0800

Product Code: 2CTB815708R0800

In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Mounting Type DIN-Rail
Suitable For To protect the systems against the transient overvoltage (lightning)
Version Plug-in
Brand ABB
Product Type Surge Protector
EAN 3660308525444
No. of Conductors 4
No. of Poles 4
Power Loss (W) 0.049
Height (mm) 80
Length (mm) 80
Weight (kg) 0.63
Width (mm) 120
Voltage Protection Level - Up (kV) 1.4

Description

Surge protective devices SPD type 2 protect low-voltage consumer systems against surge voltages as they are tested as SPD type 2 according to IEC 61643-11. The devices are compatible with the System pro M compact series. The SPD with "TS" are optionally equipped with a auxiliary contact. The variants with "reserve varistor" (s) offer additional protection for the system, as the SPD is not completely disconnected from the mains at the end of its service life, but with an additional smaller varistor still guarantees basic protection and the system thus until the surge arrester is replaced is still protected

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
