Load break switching and isolation according to AS/NZS 60947.3 Finger safe terminals with IP20 degree of protection Consistent design to all the system pro M DIN rail products Captive screws with recessed head Locking device as accessory for unauthorized ON/OFF switching Cross wiring with MCBs or RCDs using busbars PS Pole configuration 4P

Specifications

Housing Material	Insulation Group II, RAL 7035
Width in Number of Modular Spacings	4
Mounting Type	DIN Rail
Brand	ABB
Product Type	Switch Disconnector
Series	SHD200
AC Voltage (V)	400/415
Application	Domestic
Current Rating (A)	40
Family	SHD200
Impulse Withstand Voltage (kV/1.2µS)	4
Maximum Operational Voltage AC (V)	436
Minimum Operational Voltage AC (V)	12
No. of Normally-open Contacts	4
No. of Poles	4
Power Loss (W)	2.53/Pole
Rated Conditional Short-Circuit Current - Inc (kA)	10
Rated Current (A)	40
Rated Frequency (Hz)	50/60
Rated Impulse Withstand Voltage (kV)	4
Rated Insulation Voltage (V)	440
Rated Operational Voltage AC (V)	415
Rated Voltage (V)	415
Rated Voltage AC (V)	415
Switching Type	Off Switch
Cable Cross Section - Flexible (mm²)	Top/Bottom - 16/16
Cable Cross Section - Solid/Stranded (mm²)	Top/Bottom - 25/25
Dimensions (mm)	70W x 85H x 69D
Pole Width (mm)	17.5
Voltage Type	AC
Built-in Depth (mm)	69
Degree of Protection	IP20
Pollution Degree	3
Standards and Approvals	AS/NZS 60947-3
Poles	4P
Inc-Rated Conditional Short Circuit Capacity (kA)	10

Description

SHD204/40 - Switch Disconnector 4P, 40A
