NOVARIS THREADED SIGNAL SURGE PROTECTOR 1 PAIR 10kA SLT1-68-M20

Product Code: SLT1-68-M20

  • - Multistage design - Transverse and common mode - Thread size M20 x 1.5 - High transient suppression & low let-through voltages - Stainless steel enclosure
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Lightning Impulse Current (10/350 µs) - Iimp (kA) 1.25 kA per line (2.5 kA common mode)
Mounting Type Threaded
Operational Temperature Range (°C) -40 to 85
Brand NOVARIS
Product Type Signal Line Protector
Series SLT
Connection Type Shunt
Maximum Continuous Operating Voltage MCOV AC (V) 50
Maximum Continuous Operating Voltage MCOV DC (V) 65
Maximum Discharge Current (8/20µs) - Imax (kA) 5 (per line), 10 (common mode)
No. of Pairs 1
Thread Size M20 x 1.5
Voltage Protection Level (1kV/µs) - Up (kV) 0.1 (L-L), 0.350 (L-PE )
Degree of Protection IP67
Standards and Approvals IEC 61643-21, AS/NZS 1768, UL 1449 & UL 497B, ITU-T K.44

Description

Threaded Signal Surge Protector 1 pair, Maximum continuous operating voltages (Uc) 65VDC & 50VAC, Maximum discharge current (Imax) at 8/20µs 5 kA per line (10 kA common mode), Voltage protection levels at @ 1 kV/µs between <100V (L-L) & < 350 V (L-PE ). Shunt connection, IP67 (installed) thread size M20 x 1.5. Ideal for twisted pair signalling schemes, installed directly at field equipment
