Specifications

Material	clamp body & shaft - Copper alloy/gal Sn pressure plate - St/gal Zn
Ambient Temperature Range (°C)	–25 - +55
Clamping Range (mm)	20
Reference No.	774234
Suitable For	Earthing
Brand	DEHN
Product Type	Clamps and Connectors
Type	Short-Circuiting Devices
Connection Type	Fixed ball point 20/25 mm
Maximum Output Short-circuit Current (A)	33501 (0.5s), 23700 (1s)
Dimensions (mm)	35(W) x229(H) x69(D)
Weight (kg)	0.772
Wire Cross Section (mm²)	17 - 120
Standards and Approvals	EN/IEC 61230 (DIN VDE 0683-100)
