Specifications

Housing Material	Brass
Maximum Ambient Temperature (°C)	70
Minimum Ambient Temperature (°C)	-25
Installation Conditions	Flush
Enclosure Coating Material	Nickel-plated
Brand	SCHMERSAL
Included	2 x Nuts M18
Current for Voltage Drop (A)	0.2
Maximum Operational Voltage (V)	30
Maximum Voltage Drop (V)	1.2
Minimum Operational Voltage (V)	10
No. of Cables	3
Rated Operational Current (mA)	200
Switching Element	NO Contact
Switching Frequency (Hz)	700
Termination	Connector M12
Sensor Length (mm)	51
Degree of Protection	IP67
Standards and Approvals	EN IEC 60947-5-2
