SCHMERSAL IFL15-333-10/01-M20 INDUCTIVE PROXIMITY SWITCH 101161734

Product Code: 101161734

  • Position switch with metal enclosure Actuating element: Roller lever Switching elements: 1 NO contact and 1 NC contact Thermal test current: 10 A Utilisation category AC-15: 230 VAC, 4 A Utilisation category DC-13: 24 VDC, 4 A IP Rating: IP67 for dust and water resistance Operating temperature range from -30 °C to +80 °C
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Actuator Type Roller lever
Enclosure Material Plastic, glass-fibre-reinforced
Mounting Type Threaded
Storage Temperature (°C) -25 to 85
Maximum Ambient Temperature (°C) 90
Maximum Temperature (°C) 70
Minimum Ambient Temperature (°C) -25
Minimum Temperature (°C) -25
Gross Weight (g) 4
Net Weight (g) 45
Wire Cross-Section 0.75 mm
Brand SCHMERSAL
Product Type Proximity Switch
Series IFL
Working Principle Electromechanical
Housing Construction Form Norm construction design
EAN 4030660000000
eCl@ss Number, Version 9.0 27-27-27-04
ETIM 7.0 EC002549
ETIM 6.0 EC002549
eCl@ss Number, Version 11.0 27-27-27-04
Cable Note All indications including the conductor ferrules.
Contact Material Silver
Maximum Actuating Speed (m/s) 1
Maximum Cable Cross Section (mm²) 1.5
Maximum Fuse Rating 6 A gG D-fuse
Maximum Nominal Output Voltage DC (V) 4.5
Minimum Cable Cross Section (mm²) 1 x 0.5
Minimum Mechanical Life 1000000 Operations
Minimum Positive Break Force (N) 40
No. of Auxiliary Contacts 2
No. of Safety Contacts 3
Nominal Output Current (A) 0.5
Overvoltage Category 3
Rated Impulse Withstand Voltage (kV) 6
Rated Insulation Voltage (V) 400
Rated Maximum Operational Voltage AC (V) 250
Rated Minimum Operational Voltage AC (V) 15
Rated Short-circuit Current (A) 1000
Switching Element 1 NO contact, 1 NC contacts
Switching Principle Slow action
Terminal Type Connector
Thermal Test Current (A) 2.5
Utilisation Category DC-13 | AC-15
Utilisation Category DC-13 0.05 A
Sensor Length (mm) 32.5
Sensor Height (mm) 107
Degree of Protection IP65
Standards EN IEC 61496-1 / EN IEC 61496-2

Description

Discover the Schmersal IFL Series Inductive Proximity Switch, a robust sensor designed for precise position detection in industrial environments. This AC 2-wire block proximity switch boasts a notable 15 mm sensing distance and is equipped with both NO and NC contact switching elements. The durable plastic enclosure ensures longevity, while the operating voltage range of 15-250VAC at 500 mA caters to various applications. With a switching frequency of 10 Hz and digital output specifications of 4.5 V and 0.2 A, this sensor maintains reliable performance even with inductive interference protection. Suitable for extreme temperatures ranging from -25°C to 70°C, it also meets IP65 standards according to EN 60529 for dust and water resistance, making it an ideal choice for engineers seeking dependable position sensors in challenging conditions.
