Specifications

Product Type	METERING MODULE 40mA SCU200
Brand	ABB
Application	Power quality
Communication Interface	InSiteModularBus
Product Compatibility	SCU200
Rated Current (In)	0 - 40 mA
Rated Operational Current AC-15 (Ie)	0.7 A
Accuracy Class	0.5% Activeenergy (1/0.8 PF)
Power Consumption	0.007 kW
Rated Frequency	50/60 Hz
Supply Voltage	240 V
Mounting Type	DIN-Rail
Depth	64.9 mm
Height	87 mm
Weight	0.052 kg
Width	17.4 mm
IP Rating	IP20
Ambient Temperature	Operation -25 ... 60 °C
Standards and Approvals	EN 61010-1 / IEC 61010-1 EN IEC 61326-1

ABB INS-E3 METERING MODULE 40mA SCU200
