Specifications

Product Type	SMART SIGNALLING DEVICE SCU100&SCU200
Brand	ABB
Communication Interface	InSite bus(Flat cable)
Product Compatibility	SCU100 & SCU200
Rated Operational Current AC-15 (Ie)	0.7 A
Suitable For	MCBs S200 series, S300P RCDs F200, DS201 AFDDs S-ARC1, DS-ARC1 Switch disconnectors SD200
Power Consumption	0 kW
Mounting Type	DIN-Rail
Depth	64.9 mm
Height	87 mm
Weight	0.030 kg
Width	8.8 mm
IP Rating	IP20
Ambient Temperature	Operation -25 ... 60 °C
Standards and Approvals	EN 61010-1 / IEC 61010-1 EN IEC 61326-1 IEC 60068 EC / EN 62019 for Main functionality IEC 60947-5-1 for Main functionality EC61009 for RCDs compatibility EN 60898-1 for MCBs compatibility

ABB INS-S/H SMART SIGNALLING DEVICE SCU100&SCU200 FOR INSITE PRO M COMPACT SMART SIGNAL/AUXILIARY CONTACT
