| Product Type |
Firewall |
| Brand |
Hirschmann |
| Series |
OpenBAT-R / -F |
| Development Software |
Industrial HiVision , LANConfig , optional BAT Controller (WLC for AccessPoint mode) |
| Connectors |
2x N-Type Female Socket, requires N-Type Male Connectors on the Antenna
1x 10/100/1000Mbit/s |
| Rated Power |
Maximum power consumption : 9 W |
| Rated Voltage |
PoE PD 802.3af Class 3 , 24 VDC (18-32 VDC) |
| Housing Material |
Metal |
| Material |
metal |
| Mounting Type |
Wall mounting |
| Depth |
50 mm |
| Height |
150 mm |
| Weight |
934 g |
| Width |
172 mm |
| Storage Temperature |
-40-+70 °C |
| Operating Temperature |
-40-+70 °C |
| IP Rating |
IP65/67 |
| Port Type |
1x Ethernet M12 X-Coded , 1x Power M12 A-Coded |
| Communication |
1 x Ethernet M12 X Coded (10/100/1000 BASE-TX) |
| Radio Frequency |
Supports 2.4 GHz or 5 GHz: 2412-2472 MHz or 5180-5825 MHz (regulatory restrictions apply depending on the country of operation) |
| Modulation |
OFDM: BPSK, QPSK, DBPSK, DQPSK, 16-QAM, 64-QAM, 256-QAM; Note: MCS numbering changed with 11ac. Supported rates with up to 2 streams: MCS0-MCS9. Channel widths: 20MHz, 40MHz and 80MHz |
| Radio Features |
2x2 MIMO (configurable). Up to 2 streams (configurable). Spatial Multiplexing, Cyclic-Delay Diversity (CDD), Low-Density Parity Check (LDPC) Codes, Maximal Ratio Combining (MRC), Space Time Block Code (STBC) |
| Encryption |
Open, WEP, 802.11i - WPA/WPA2 - Personal (PSK), 802.11i - WPA/WPA2 - Enterprise (802.1X: TLS, TTLS/PAP, TTLS/CHAP, TTLS/MSCHAP, TTLS/MSCHAPV2, TTLS/MD5, PEAP/MSCHAPV2) |
| Communication Protocols |
IEEE 802.11a/b/g/n/ac WLAN interface as per IEEE 802.11ac , 802.11F (IAPP) as Access Point, 802.11r as Access Point |
| Standards and Approvals |
FCC, IC
IEC/EN 62368-1:2014 + AC:2015 (formerly EN 60950-1), EN 62311:2008
ETSI EN 300 328:2019 V2.2.2 (2.4GHz), ETSI EN 301 893:2017 V2.1.1 (5GHz), ETSI EN 302 502:2017 V2.1.1 (5.8GHz) |
