| Brand |
Circutor |
| Series |
computer C Wi-Fi |
| Location of Connection |
Connect preferably to phase L1 |
| Nominal Current (In) |
… / 5 A |
| Nominal Voltage (AC Primary) |
230 V ~ (±10 %) |
| Type of Electric Connection |
Connect preferably to phase L1 |
| Rated Frequency |
50 … 60 Hz |
| Mechanical Life |
1x107 cycles |
| ETIM 9.0 Class |
EC002758 |
| Installation Category (AC Supply) |
CAT III 300 V |
| Permanent Overload (Electrical) |
+ 20% |
| Permanent Overload (Per Transformer) |
+ 20% |
| Phase Current Measuring Range |
0.05 ... 5A |
| Phase Voltage Measurement |
1% |
| Phase Current Measurement |
1% |
| Phase Angle f |
2 % ± 1 digit |
| Quantity (Relay Outputs) |
6 + 1 (Alarm) |
| Max. Open Contact Voltage |
250 V~ |
| Max. Current (Relay Outputs) |
1 A~ |
| Max. Switching Capacity |
250 W |
| Electrical Life at Maximum Load |
1x105 cycles |
| Envelope |
Plastic V0 self-extinguishing |
| Fastening/Setting |
Panel |
| Cable Gauge at Current Terminals |
≥1,5 mm² |
| Cable Gauge at Power Supply Terminals |
≥1,5 mm² |
| Working Temperature |
-20 … +60 ºC |
| Protection Class |
IP 30 / Front Panel: IP 40
IK 08 |
| Electrical Safety, Contamination Level/Class |
Pollution resistance 2 |
| Electrical Safety, Insulation |
Double-insulated electric shock protection class II (IEC 61010-1) |
| AC Power Consumption |
4,7 VA |
| Nominal Voltage (AC Supply) |
230 V ~ (±10 %) |
| Cable Gauge at Input and Output Terminals |
≥1,5 mm² |
| Keyboard |
3 keys |
| Depth |
54.85 mm |
| Height |
144 mm |
| Weight |
0.558 kg |
| Width |
144 mm |
| Electrical Safety, Maximum Height (M) |
2000 |
| Relative Humidity (Without condensation) |
5 … 95 % |
| Storage Temperature |
-20 … +70 ºC |
| Resolution of the Display |
3 digits |
| Standards |
IEC 61010, IEC 61000-2-30, IEC 61000-6-4, IEC 61000-6-2 |
