Specifications

Brand	Circutor
Series	SmartLink-VAR
Nominal Voltage (AC Primary)	100 … 264 V ~
LED Indication	6 LED
Power Consumption	1.6 … 2 W
Rated Frequency	50 … 60 Hz
Fixing Screw Type	Flat, M2.5
Band	2.4 GHz (IEEE 802.11 b / g , IEEE 802.11 n (up 150 Mbps)
ETIM 9.0 Class	EC000310
Installation Category (AC Supply)	CAT III
Installation Category (DC Supply)	CAT III
Technology / Type (Serial)	RS-485
Protocol (Network)	TCP/IP\|UDP\|Modbus TCP/IP\|HTTTP (Web server)-REST
Technology / Type (Wireless)	Wi-Fi
Envelope	Self-extinguishing V0 plastic
Fastening/Setting	DIN rail
Torque Setting	&#8804; 0.4 Nm
Cable Gauge at Power Supply Terminals	2.5 mm²
Communications Cable Cross-Section	2.5 mm²
Working Temperature	-20 … +60 ºC
Protection Class	IP30, Front: IP40 \| IK08
AC Power Consumption	2 … 7 VA
Nominal Voltage (DC Supply)	120 … 300 Vdc
Depth	70 mm
Height	109.45 mm
Weight	0.192
Width	35 mm
Electrical Safety, Maximum Height (M)	2000
Technology / Interface	Ethernet
Relative Humidity (Without condensation)	5 … 95 %
Storage Temperature	-20 … +70 ºC
Standards	EN 62368-1:2020/A11:2020/ AC:2020-05, EN 50663: 2017, ETSI EN 301 489-1 V2.2.3, ETSI EN 301 489-17 V3.2.4, ETSI EN 301 893 V2.1.1

CIRCUTOR R1LVAR SMARTLINK MODULE RS-485 TO ETHERNET/WIFI SmartLink-VAR
