Specifications

Rated Short Circuit Breaking Capacity, (Ics) 690V AC	12 kA
Rated Short Circuit Breaking Capacity, (Icu) 690V AC	12 kA
Rated Ultimate Short Circuit Breaking Capacity (Icu) at 415 V, 50 Hz	50 kA
Product Type	Automatic Circuit Breaker
Brand	ABB
Series	SACE Tmax XT
Application	Power Distribution
Connection Type	Front
AC Power Loss Per Pole at In	0.60 W
Max. Rated Operation AC Voltage (Ue)	690 V AC
Position of Connection for Main Current Circuit	Front
Rated Current (In)	40 A
Rated Impulse Withstand Voltage (Uimp)	8 kV
Rated Insulation Voltage (Ui)	1000 V AC
Suitable For	XT4S
Type of Protection Trip Unit	EL
Breaking Capacity	50 kA
Power Loss	0.6 W
Rated Current	40 A
Rated Frequency	50/60 Hz
Rated Voltage	690 VAC
Trip Curve	Ekip C Dip LSIG
Type	Fixed
Terminal Type	Bolt
Electrical Life	8000 cycles
Mechanical Life	25000 cycles
No. of Poles	4
Depth	82.5 mm
Height	160 mm
Weight	3500 g
Width	140 mm
IP Rating	IP20
Standards and Approvals	IEC 60947-2
