Specifications

Product Type	HVACR Drives
Brand	ABB
Series	ACH580
Application	Industrial, Commercial And Domestic
No. of Analog Inputs	2
No. of Digital Inputs	6
No. of Digital Outputs	3
No. of Phases	3
Communication Ports	2
Rated Current	430 A
Rated Frequency	500 Hz
Rated Power	250 kW
Rated Voltage	380-480 VAC
No. of Input Phases	3-phase
Nominal Input Voltage	380 ... 480 V
Normal Duty Amps	430 A
Normal Duty kW	250 kW
Heavy Duty Amps	363 A
Heavy Duty kW	200 kW
Control Panel (Keypad)	Yes
Frame Size	R9
Mounting Style	Wall-mounted
Mounting Type	Wall
Depth	477 mm
Height	955 mm
Weight	103 kg
Width	380 mm
Operating Temperature	Maximum 40 °C Minimum -15 °C
IP Rating	IP55
Serial Ports	1
USB Port	1
Communication Protocols	TCP/IP PROFIBUS CAN MODBUS DeviceNet / DeviceNet Safety LON PROFINET IO EtherNet/IP BACnet Other Bus Systems
Standards and Approvals	UNSPSC:39122001
