Specifications

Product Type	Industrial Drive With B'CP
Brand	ABB
Series	ACS880
No. of Analog Inputs	2
No. of Phases	3
Rated Current	246 A
Rated Power	132 kW
Rated Voltage	380-415 VAC
No. of Input Phases	3-phase
Nominal Input Voltage	380 ... 415 V
Normal Duty Amps	246 A
Normal Duty kW	132 kW
Heavy Duty Amps	206 A
Heavy Duty kW	110 kW
Control Panel (Keypad)	Yes
Frame Size	R8
Mounting Type	Wall
Depth	300 mm
Height	963 mm
Weight	68 kg
Width	300 mm
Operating Temperature	-15 to 40 deg C
IP Rating	IP55
Standards and Approvals	CE/ EN 61800-5-1:2007/ EMC/ ATEX/ RoHS 2011/65/EU/ TÜV/ UL 508C/ CSA
