Specifications

Product Type	Safety Contactors
Brand	ABB
No. of Auxiliary Contacts	3
Rated Control Supply Voltage (Us)	100 ... 250 VAC/DC
Rated Operational Current AC-1 <= 690V (Ie)	275 A
Rated Operational Current AC-1 1000V (Ie)	250 A
Rated Operational Current AC-3 1000V (Ie)	85 A
Rated Operational Current AC-3 400V (Ie)	190 A
Rated Operational Current AC-3 690V (Ie)	135 A
Rated Operational Power AC-3 1000V (Pe)	110 kW
Rated Operational Power AC-3 400V (Pe)	90 kW
Rated Operational Power AC-3 690V (Pe)	132 kW
Rated Frequency	50 / 60 Hz
No. of Poles	3P
Depth	152 mm
Height	196 mm
Weight	2.4 kg
Width	105 mm
Ambient Temperature	-40 ... 70 °C
Standards and Approvals	IEC 60529, IEC 60947-1, EN 60529
