Specifications

Product Type	Safety Contactors
Brand	ABB
No. of Auxiliary Contacts	3
Rated Control Supply Voltage (Us)	100 ... 250 VAC/DC
Rated Operational Current AC-1 <= 690V (Ie)	600 A
Rated Operational Current AC-1 1000V (Ie)	400 A
Rated Operational Current AC-3 1000V (Ie)	141 A
Rated Operational Current AC-3 400V (Ie)	370 A
Rated Operational Current AC-3 690V (Ie)	315 A
Rated Operational Power AC-3 1000V (Pe)	200 kW
Rated Operational Power AC-3 400V (Pe)	200 kW
Rated Operational Power AC-3 690V (Pe)	315 kW
Rated Frequency	50 / 60 Hz
No. of Poles	3P
Depth	180 mm
Height	225 mm
Weight	4 kg
Width	140 mm
Ambient Temperature	-40 ... 70 °C
Standards and Approvals	IEC 60529, IEC 60947-1, EN 60529
