Specifications

Product Type	Safety Contactors
Brand	ABB
No. of Auxiliary Contacts	3
Rated Control Supply Voltage (Us)	24 ... 60 VDC
Rated Operational Current AC-1 <= 690V (Ie)	700 A
Rated Operational Current AC-1 1000V (Ie)	700 A
Rated Operational Current AC-3 1000V (Ie)	200 A
Rated Operational Current AC-3 400V (Ie)	460 A
Rated Operational Current AC-3 690V (Ie)	400 A
Rated Operational Power AC-3 1000V (Pe)	280 kW
Rated Operational Power AC-3 400V (Pe)	250 kW
Rated Operational Power AC-3 690V (Pe)	355 kW
Rated Frequency	50 / 60 Hz
No. of Poles	3P
Depth	216 mm
Height	278 mm
Weight	10.6 kg
Width	186 mm
Ambient Temperature	-40 ... 70 °C
Standards and Approvals	IEC 60529, IEC 60947-1, EN 60529
