Specifications

Product Type	Three-Phase Monitoring Relays
Brand	ABB
Contact Configuration	1CO SPDT
Contact Form	1CO SPDT
Degree of Pollution	IP3
Degree of Protection	IP20, IP50
Function	Phase Failure Detection Neutral Monitoring
Height	78 mm
LED Colour	F: Red, R: Yellow
Measuring Range	208-440 VAC (L-L)
Mounting Type	35 x 15 mm DIN Rail, 35 x 7.5 mm DIN Rail
Operating Time	500 ms Start-Up Delay, 500 ms Tripping Delay
Output Type	1CO SPDT
Phase	3
Rated Current	4 A
Rated Frequency	50/60 Hz
Rated Voltage	200-500 VAC
Standards and Approvals	CAN/CSA IEC/EN UL
Terminal Type	Screw
Weight	0.068 kg
Width	22.5 mm
