Specifications

Product Type	Three-Phase Monitoring Relays
Brand	ABB
Contact Configuration	2CO SPDT
Contact Form	2CO SPDT
Degree of Protection	IP50 (Housing), IP20 (Terminals)
Function	Phase Failure Detection Phase Sequence Monitoring
Height	85.6 mm
LED Colour	F: Red, R: Yellow
Measuring Range	200-500 VAC (L-L)
Mounting Type	DIN Rail
Operating Time	500 ms Start-Up Delay
Operational Temperature	-20 to 60 deg C
Output Type	2CO SPDT
Phase	3
Rated Voltage	200-500 VAC
Standards and Approvals	CAN/CSA IEC/EN UL
Terminal Type	Screw
Weight	0.127 kg
Width	22.5 mm
