Specifications

Product Type	Monitoring Relay
Brand	ABB
Connecting Capacity	Flexible with Ferrule 1x 0.5 ... 2.5 mm² Flexible with Ferrule 2x 0.5 ... 1.5 mm² Flexible with Insulated Ferrule 1x 0.5 ... 2.5 mm² Flexible with Insulated Ferrule 2x 0.5 ... 1.5 mm² Flexible 1x 0.5 ... 2.5 mm² Flexible 2x 0.5 ... 1.5 mm² Rigid 1x 0.5 ... 4 mm² Rigid 2x 0.5 ... 2.5 mm²
Contact Configuration	1 C/O (SPDT)
Contact Form	1CO SPDT
Degree of Pollution	IP3
Degree of Protection	Housing IP50 Terminals IP20
Dimensions	85.6Hx22.5Wx 103.7D mm
Electrical Durability	100000 Operations
Function	Over- or undercurrent monitoring
Gross Weight	0.159 kg
Height	85.6 mm
LED Colour	U/T: Green, I: Red, R: Yellow
Measuring Range	0.3 - 1.5 A 1 - 5 A 3 - 15 A
Mechanical Durability	30000000 Operations
Mounting Type	35 x 15 mm DIN Rail 35 x 7.5 mm DIN Rail
Net Weight	0.137 kg
Operational Temperature	Operation -20 - +60 °C
Output Type	1CO SPDT
Overvoltage Category	III
Rated Current	4 A
Rated Frequency	50/60 Hz
Rated Impulse Withstand Voltage	Measuring Circuit / Output Circuit 6 kV Output Circuit 1 / Output Circuit 2 4 kV Supply Circuit / Measuring Circuit 6 kV Supply Circuit / Output Circuit 4 kV
Rated Operational Current	4A (230V, AC-12)
Rated Voltage	110-130 VAC
Standards and Approvals	CAN/CSA C22.2 No.14 IEC/EN 63000 IEC/EN 60255-27 IEC/EN 61000-6-2 IEC/EN 61000-6-3 UL 508
Terminal Type	Screw
Tightening Torque	0.6 - 0.8 Nm
Weight	0.168 kg
Width	22.5 mm
Rated Control Supply Voltage	24 ... 240 V AC/DC
Minimum Switching Capacity	24 V 10 mA
