Specifications

Product Type	Power Supply
Brand	ABB
Series	C
Ambient Temperature	-40 to 70 deg C
Connecting Capacity	0.5-2.5 sq-mm Flexible, 0.5-4 sq-mm Rigid
Degree of Pollution	IP2
Degree of Protection	IP20
Length	136 mm
Mounting Type	DIN Rail
Phase	1
Rated Current	10 A
Rated Frequency	50/60 Hz
Rated Power	240 W
Rated Voltage	85-264 VAC
Standards and Approvals	CAN/CSA C22.2 No.107.1, IEC/EN 63000, IEC/EN 60079-0, IEC/EN 60079-15, IEC/EN 60079-7, IEC/EN 61000-6-2, IEC/EN 61000-6-3, IEC/EN 61204, UL 508, UL 61010-1, UL 61010-2-201, IEC/EN 61010-1cULus, CE, RoHS, REACH
Tightening Torque	0.5 N-m
Width	60 mm
Wire Stripping Length	8 mm
