Specifications

Product Type	Power Supply
Brand	ABB
Series	C
Ambient Temperature	-40 to 70 deg C
Connecting Capacity	0.2-2.5 sq-mm Flexible, 0.2-2.5 sq-mm Rigid
Degree of Pollution	IP2
Degree of Protection	IP20
Depth	57.5 mm
Height	91 mm
Mounting Type	DIN Rail
Phase	1
Rated Current	4.2 A
Rated Frequency	50/60 Hz
Rated Power	100 W
Rated Voltage	90-264 VAC, 24 VDC
Standards and Approvals	CAN/CSA C22.2 No.107.1, CAN/CSA C22.2 No.223, CAN/CSA C22.2 No.60950, IEC/EN 63000, IEC 60950-1, IEC/EN 61000-6-2, IEC/EN 61000-6-3, UL 1310, UL 508, UL 60950cULus, CE, RoHS, REACH
Tightening Torque	0.7 N-m
Width	89.9 mm
Wire Stripping Length	7 mm
