Specifications

Product Type	Power Supply
Brand	ABB
Series	C
No. of Phases	1
Rated Current	2.5 A
Rated Frequency	50 Hz
Rated Power	30 W
Rated Voltage	85-264 VAC, 12 VDC
Connecting Capacity	0.2-2.5 sq-mm Flexible, 0.2-2.5 sq-mm Rigid
Mounting Type	DIN Rail
Tightening Torque	0.6 N-m
Wire Stripping Length	6 mm
Depth	114 mm
Height	90 mm
Width	40.5 mm
Pollution Degree	2
Operating Temperature	-40 to 70 deg C
IP Rating	IP20
Standards and Approvals	ANSI/ISA-12.12, CAN/CSA C22.2 No.107.1, CAN/CSA C22.2 No.213, CAN/CSA C22.2 No.223, CAN/CSA C22.2 No.60950, IEC/EN 63000, IEC 60950-1, IEC/EN 61000-6-2, IEC/EN 61000-6-3, UL 1310, UL 508, UL 60950cULus, CE, RoHS, REACH
