Specifications

Product Type	Power Supply
Brand	ABB
Series	C
Ambient Temperature	-40 to 70 deg C
Connecting Capacity	0.2-4 sq-mm Flexible, 0.2-6 sq-mm Rigid
Degree of Protection	IP20
Depth	123.6 mm
Height	123.6 mm
Mounting Type	DIN Rail
Phase	1
Rated Current	20 A
Rated Frequency	50 Hz
Rated Power	480 W
Rated Voltage	90-264 VAC, 24 VDC
Standards and Approvals	ANSI/ISA-12.12, CAN/CSA C22.2 No.107.1, CAN/CSA C22.2 No.213, CAN/CSA C22.2 No.60950, IEC/EN 63000, IEC 60950-1, IEC/EN 61000-6-2, IEC/EN 61000-6-3, UL 508, UL 60950cULus, CE, RoHS, REACH
Tightening Torque	1 N-m, 0.62 N-m
Width	175 mm
Wire Stripping Length	8 mm
