Specifications

Product Type	Pluggable Interface relay
Brand	ABB
Series	CR-M
Actuating Voltage	24V DC
No. of Change-Over Contacts	3
Rated Insulation Voltage (Ui)	250 V
Contact Configuration	3CO SPDT
Electrical Connection	Flat-Pin Connections
Rated Current	10 A
Rated Voltage	250 V AC
Terminal Type	Flat Plug-In Connector
Contact Material	AgNi
Model	Pluggable Miniature Interface Relay CR-M
Mounting Type	Socket
Depth	27.5 mm
Height	35.6 mm
Length	27.5 mm
Weight	0.033 kg
Width	21.2 mm
Operating Temperature	-40 to 70 deg C
IP Rating	IP40
Ambient Temperature	-40 ... +70 °C
Standards and Approvals	CAN/CSA C22.2 No.14,IEC/EN 63000,IEC/EN 61810-1,UL 508
