Specifications

Product Type	Pluggable Interface relay
Brand	ABB
Series	CR-P
Actuating Voltage	24V DC
No. of Change-Over Contacts	1
Contact Configuration	1CO SPDT
Electrical Connection	Soldering Pins
Output Type	1CO SPDT
Rated Current	16 A
Rated Frequency	50/60 Hz
Rated Voltage	250 V AC
Terminal Type	Solder
Contact Material	AgNi
Model	Pluggable PCB Interface Relay CR-P
Mounting Type	Socket
Depth	29 mm
Height	15.7 mm
Weight	0.014 kg
Width	12.7 mm
Operating Temperature	-40 to 70 deg C
IP Rating	IP67
Ambient Temperature	-40...+85 ° °C
Standards and Approvals	IEC/EN 61810-1
