Specifications

Product Type	Residual Current Device Block
Brand	ABB
Ambient Temperature	-25 to 55 deg C
Cable Cross Section	16-16 sq-mm Rigid/Flexible
Degree of Protection	IP2X
Depth	76 mm
Electrical Durability	10000 Cycles
Height	96 mm
Number of Poles	4
Power Loss	4.8 W
Rated Current	40 A
Rated Frequency	50/60 Hz
Rated Impulse Withstand Voltage	4 kV
Rated Insulation Voltage	500 V
Rated Voltage	230/400 VAC
Residual Current Type	Type A
Standards and Approvals	IEC/EN 61009
Weight	0.173 kg
Width	105 mm
