Specifications

Rated Short-Circuit Breaking Capacity (Icn) acc. To IEC/EN 61009-1	6 kA
Rated Short-Circuit Breaking Capacity (Icu) acc. To IEC/AS/NZS 61009	10 kA
Product Type	RCBO
Brand	ABB
Series	DS203
Electrical Endurance	10000
No. of Poles (Total)	3P+N
Rated Impulse Withstand Voltage (Uimp)	4 kV
Rated Insulation Voltage (Ui)	500 V
Power Loss	15.1 W
Rated Current	32 A
Rated Frequency	50 / 60 Hz
Rated Voltage	415 V
Trip Curve	C
Rated Residual Current	30 mA
Type of Residual Current	Type A
Conductor Cross Section Flexible	25 mm²
Conductor Cross Section Solid Core	25 mm²
Mechanical Endurance	20000
Mounting Type	DIN rail
Depth	69 mm
Height	85 mm
Weight	0.48 kg
Width	71 mm
Width in No. of Modular Spacing	4
Pole Width	18 mm
Rated Surrounding Temperature without Derating	30°C
Pollution Degree	2
Storage Temperature	-40…+70°C
Operating Temperature	-25 … 55 °C
IP Rating	IP2X, IP4X
Standards and Approvals	IEC 60898-1, IEC/EN 60664-1
