Specifications

Rated Short-Circuit Breaking Capacity (Icn) acc. To IEC/EN 61009-1	10 kA
Product Type	RCBO
Brand	ABB
Series	DSE203
Electrical Endurance	10000
No. of Poles (Total)	3P+N
Rated Impulse Withstand Voltage (Uimp)	4 kV
Rated Current	25 A
Rated Frequency	50 / 60 Hz
Rated Voltage	415 V AC
Trip Curve	C
Terminal Type	Pillar terminals
Rated Residual Current	30 mA
Type of Residual Current	Type A
Conductor Cross Section Flexible	16/16 mm²
Conductor Cross Section Solid Core	25/25 mm²
Housing Type	Insulation group I, RAL 7035
Mechanical Endurance	20000
Mounting Type	DIN rail
Depth	72 mm
Height	117.5 mm
Weight	0.549 kg
Width	53.4 mm
Width in No. of Modular Spacing	4
Pole Width	18 mm
Rated Surrounding Temperature without Derating	30°C
Pollution Degree	2
Storage Temperature	-40…+70°C
Operating Temperature	-25 … 55 °C
IP Rating	IP2X, IP4X
Standards and Approvals	IEC 61009-1, IEC 61009-2-2, AS/NZS 61009.1
