Specifications

Rated Operational Power AC-1/AC7a 230V 1 Phase (Pe)	4.6 kW
Rated Operational Power AC-3/AC7b 230V 1 Phase (Pe)	1.3 kW
Rated Operational Current AC-3/AC7b (le) 230 V1 phase	9A
Product Type	Installation Contactors
Brand	ABB
No. of N/C Contacts	2
No. of Poles (Total)	2
Rated Control Supply Voltage (Us)	220 V DC 240 V AC
Rated Operational Current AC-1/AC7a (Ie)	20
Rated Frequency	50/60 Hz
Depth	65 mm
Height	85 mm
Weight	0.14 kg
Width	18 mm
Ambient Temperatures	-25 ... +55 °C
Standards and Approvals	IEC/EN 60947-1, IEC/EN 60947-4-1, IEC/EN 61095
