Specifications

Rated Short-Circuit Breaking Capacity (Icn) acc. To IEC/EN 61009-1	10 kA
Product Type	RCCB
Brand	ABB
Series	F200
Electrical Endurance	10000
No. of Poles (Total)	1P+N
Rated Impulse Withstand Voltage (Uimp)	4 kV
Rated Insulation Voltage (Ui)	500 V
Rated Current	25 A
Rated Frequency	50 / 60 Hz
Rated Voltage	230 V
Terminal Type	Screw Terminals
Rated Residual Current	30 mA
Type of Residual Current	Type A
Conductor Cross Section Solid Core	1 - Solid-Core 25...25 mm²
Housing Type	Insulation group I - II, RAL 7035
Mechanical Endurance	20000
Mounting Type	DIN rail
Depth	69 mm
Height	85 mm
Weight	0.200 kg
Width	35 mm
Width in No. of Modular Spacing	2
Pole Width	18 mm
Rated Surrounding Temperature without Derating	30°C
Pollution Degree	2
Storage Temperature	-40…+70°C
Operating Temperature	-25 … 55 °C
IP Rating	IP2X, IP4X
Standards and Approvals	IEC 61009-1, IEC 61009-2-2, AS/NZS 61009.1
