Specifications

Product Type	Auxiliary contact block
Brand	ABB
Series	SMISSLINE TP
No. of Auxiliary Contacts NO	2
No. of N/C Contacts	2
No. of N/O Contacts	0
Switching Current	2 A
Switching Voltage	230 V AC
Contact Configuration	2NC
Power Loss	0.24 W
Rated Current	6 A
Rated Voltage	230 to 400 V AC
Change-Over Contacts	0
Mounting Type	Plug-In Device
Depth	75 mm
Height	92 mm
Weight	45 g
Width	9 mm
Width in No. of Modular Spacing	0.5
Standards and Approvals	IEC/EN 60947-5-1
