Specifications

Product Type	Contact bloc for IPS
Brand	ABB
Series	IPS
No. of Auxiliary Contacts NO	1
No. of N/C Contacts	1
No. of N/O Contacts	1
Rated Impulse Withstand Voltage (Uimp)	4 kV
Rated Insulation Voltage (Ui)	500 V
Type of Switching Output	Slow Action
Contact Configuration	1NC
Rated Current	4 A at 400 V AC, 6 A at 240 V AC, 10 A at 24 V AC
Rated Voltage	690 V
Terminal Type	Connector
Mechanical Durability	1 million Operations
Actuator Type	Angle Roller Lever
Cable Cross Section	(2) 1.5 sq-mm
Colour	Red, Green
Contact Material	Silver
Material	Aluminium
Shock Resistance acc. To IEC/EN 60068-2-27	30 g/ms
Depth	37 mm
Height	33 mm
Length	71.5 mm
Weight	23 g
Width	32 mm
Operating Temperature	-10 to 70 degC
IP Rating	IP65
Standards and Approvals	EN IEC 61496-1/CLC/TS 61496-2
