ABB LS30P13B11 Limit Switch Plastic Roller Plunger 30mm W

Product Code: LS30P13B11

  • Rated for 3.1 A, 10 A, 5.5 A, and 3 A
  • IP65 protection against dust and water
  • Operates in -25 to 70°C temp range
  • Compact size: 30x30x84 mm
  • Durable with 10 million operations
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Limit Switch
Brand ABB
Actuating Speed 0.3 m/s
Actuator Material Plastic
Actuator Type Roller Plunger
Degree of Protection IP65
Height 84 mm
Length 30 mm
Mechanical Durability 10000000 Operations
Number of Auxiliary Contacts 1
Operational Temperature -25 to 70 deg C
Rated Current 3.1 A, 10 A, 5.5 A, 3 A
Rated Frequency 50/60 Hz
Switching Type Snap Action
Terminal Type Screw
Weight 0.064 kg
Width 30 mm

Description

<p>For professionals in the industrial and commercial sectors, choosing the right components is crucial for ensuring efficiency and reliability. This product offers a balance of robust functionality and compact design, making it a reliable choice for various applications.</p><p>With rated currents of 3.1 A, 10 A, 5.5 A, and 3 A, this device provides versatile options to suit different electrical requirements. Its IP65 degree of protection ensures that it can withstand harsh environments by offering resistance against dust ingress and water jets from any direction. This makes it suitable for both indoor and outdoor use where environmental factors might be a concern.</p><p>Operating efficiently within a temperature range of -25 to 70 degrees Celsius, this product is designed to perform reliably under extreme conditions. Weighing just 0.064 kg with dimensions of 30 mm in length, width, and an overall height of 84 mm, its compact form factor allows for easy integration into existing systems without taking up unnecessary space.</p><p>The device features one auxiliary contact which adds flexibility to your setup by allowing additional circuit connections or control functions as needed. It employs a snap action switching type that ensures quick response times essential for precise operations.</p><p>The roller plunger actuator made from durable plastic material guarantees consistent performance while maintaining longevity even with frequent use. With an actuating speed of up to 0.3 m/s, it caters well to applications requiring rapid actuation.</p><p>Screw terminals provide secure connections that are straightforward to install or adjust during maintenance periods—a practical feature appreciated by technicians aiming for minimal downtime.</p><p>One standout aspect is its mechanical durability rated at an impressive ten million operations—highlighting the device&amp;#39;s capability to endure extensive usage over time without compromising on performance or safety standards.</p><p>Overall compatibility with standard frequencies (50/60 Hz) further enhances its adaptability across different regions globally—making this component not only versatile but also universally applicable across diverse industrial settings.</p><p>This combination of technical specifications positions the product as a dependable solution meeting high-performance demands effectively while being mindful about operational constraints such as space limitations or environmental challenges faced frequently within these industries.</p>

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
