Specifications

Product Type	Limit switch
Brand	ABB
Series	LS30
No. of N/C Contacts	1
No. of N/O Contacts	1
Type of Switching Output	Snap Action
Contact Configuration	1NO+1NC
Rated Current	3.1 A, 10 A, 5.5 A, 3 A
Change-Over Contacts	0
Mechanical Durability	10000000 Operations
Actuator Type	Plastic roller plunger
Device Construction	Plastic
Housing Material	Fiber-glass reinforced UL-V0 material
Mounting Type	30 mm EN 50047
Depth	30 mm
Height	84 mm
Length	30 mm
Weight	64 g
Width	30 mm
Operating Temperature	-25 to 70 degC
IP Rating	IP65
Standards and Approvals	CE,UL
