Specifications

Product Type	Limit switch
Brand	ABB
Series	LS40
No. of N/C Contacts	1
No. of N/O Contacts	1
Type of Switching Output	Snap Action
Contact Configuration	1NO+1NC
Rated Current	3.1 A, 10 A, 5.5 A, 3 A
Change-Over Contacts	0
Mechanical Durability	25000000 Operations
Actuator Type	Plain steel plunger
Device Construction	Steel
Housing Material	Fiber-glass reinforced UL-V0 material
Material	Plastic (Housing)
Mounting Type	40 mm EN 50041
Depth	41 mm
Height	104 mm
Length	41 mm
Weight	132 g
Width	41 mm
Operating Temperature	-25 to 70 degC
IP Rating	IP65
