Specifications

Product Type	Mini Contactor Relays
Brand	ABB
No. of N/C Contacts	1
No. of N/O Contacts	3
No. of Poles (NO/NC)	3NO/1NC
Rated Control Supply Voltage (Us)	24 V DC
Rated Operational Current AC-15 (Ie)	6 A
Rated Frequency	50/60 Hz
Depth	68 mm
Height	48 mm
Weight	0.235 kg
Width	45 mm
Ambient Temperatures	-40 ... +70 °C
Standards and Approvals	IEC/EN 60947-1 IEC/EN 60947-5-1 UL 60947-1 UL 60947-5-1
