Specifications

Product Type	Contactor Relays
Brand	ABB
Connection Type	Screw Connection for Auxiliary Circuit
Actuating Voltage	AC/DC
No. of N/C Contacts	2
No. of N/O Contacts	2
No. of Poles (NO/NC)	2NO/2NC
Operating Voltage	24-60 VAC, 20-60 VDC
Rated Control Supply Voltage (Us)	50 Hz 24 ... 60 V 60 Hz 24 ... 60 V DC Operation 20 ... 60 V
Rated Impulse Withstand Voltage (Uimp)	6 kV
Rated Insulation Voltage (Ui)	690 V, 600 V
Rated Operational Current AC-15 (Ie)	(690 V) 2 A
Timing Range	13 to 98 ms, 11 to 95 ms, 38 to 90 ms, 40 to 95 ms
Contact Configuration	2NO
Rated Current	2 A, 2 A, 6 A, 4 A, 3 A
Rated Frequency	50 / 60 Hz
Rated Voltage	20-60 VDC
Rated Withstand Current	140 A, 100 A
Terminal Type	M4 Screw
Rated Thermal Current (Ith)	16 A
Mounting Type	35 x 15 mm Mounting Rail
Wire Stripping Length	10 mm Auxiliary Circuit, 10 mm Control Circuit
Depth	77 mm
Height	86 mm
Length	77 mm
Weight	0.27 kg
Width	45 mm
Operating Temperature	-40 to 70 deg C
IP Rating	IP20
Ambient Temperature	-40 ... 70 °C
Standards and Approvals	IEC/EN 60947-1, IEC/EN 60947-5-1, UL 60335-2-40 LZGH2 A2L, UL 508, CSA C22.2 No. 60335-2-40 LZGH2 A2L, CSA C22.2 No. 14-13
